Description
Product Specification:
1. Rated Output Voltage: 110V/220V
2. Rated Output: 500W
3. Power Protection: 650W
4. Frequency Range: 50Hz/60Hz 3Hz (automatically follows input frequency)
5. Conversion Efficiency: 92%
6. Short-circuit Protection: Yes, protection lifted after short circuit is defused
7. Thermal Protection: Thermal protection activates when temperature exceeds 65C
8. Operating Mode: Long press the AC button to switch on/off, with screen displaying on/off status
Battery Characteristics:
1. Battery Type: LiFePo4
2. Total Energy: 230.4WH
Charging Function/Charging Port:
1. AC Power Voltage: AC (100-140VAC/200-240VAC), 150W max., 2H to full
2. Car Charging: Standard Car charger to XT60 line, 12-30VDC, 150W max.
3. Solar Charging: 12-30V, 150W max.
4. Adapter Charging: 12V-30V, 150W max.
5. Charging Temperature: 0~45C
DC Output:
1. TYPE-C: PD 22.5W 5-12V/2.25A; PD2.0/PD3.0/PPS, QC2.0/QC3.0, HUAWEI FCP/SCP, SAMSUNG AFC/BC1.2/DCP, APPLE 2.4, SFCP
2. USB-A1,2,3: 18W QC3.0: 5V/3A, 9V/2A, 12V/1.5A, 18W max
3. 12VDC:
a) DC5525: 12V10A (shared circuit between DC5525 and Car Charger)
b) Car Charger: Note: When DC output is in function, DC input is unavailable for DC5525 and Car Charger
4. Wireless Charging: 10W, supports 5W, APPLE 7.5W, SAMSUNG 10W
LED Illumination:
1. Modes: Low-light, High-light, SOS, Strobing
Cooling:
1. Fan
BMS Characteristics:
1. Rated Current:
a. 20A (max) for input, 26A for output
b. 20A (max) for input, 27A for output
2. Protection:
a. Overcharge Protection
b. Over-discharging Protection
c. Thermal Protection
d. Overcurrent Protection
e. Short-Circuit Protection
f. SOC Calculation
Insulation Resistance & Voltage Withstand Characteristics:
1. Insulation & Resistance: Interface to housing 2M 500Vdc
2. Voltage Withstand:
a. AC interface to housing: 2KVAC/50Hz 1min
b. Other interfaces to housing: 500VAC/50Hz 1min
Operation Noise:
1. 5dB
Weight & Dimension:
1. Host Weight: 4.23KG
2. Host Size: 250mm x 177mm x 177mm
3. Set Weight: 6.22KG
4. Package Size: 316mm x 247mm x 315mm
What's in the Box:
1 X Power Cable
1 X Product Manual
1 X [CTGEYIL](https://www.ctgeyil.com/za) Portable Power Station
