Description
Never miss a moment
This network video recorder supports up to 2x 16TB hard drive (not included) for 24/7 continuous recording.
Youll never miss a moment. Scheduled or triggered recording options, allow you to record even longer.
More Efficient Streaming for Optimum Viewing Experience
It supports video stream compression H.264+ Codec, which has advantages of storage and bandwidth savings with greater efficiency and achieves high quality video preview and recording in low-bit rate.
Supports ultra-long continuous 24/7 recording (supports external hard drive up to 16TB).
The table below shows how long the Foscam NVR can record 24/7 under different HDD capacities for reference.
Power over Ethernet (PoE)
Power over Ethernet (PoE camera) for easy installation, no matter day or night, rain or shine.
16 channels UHD IP camera input
HDMI output 1 x HDMI
VGA output 1 x VGA
Screen resolution 3840 x 2160, 2560 x 1440, 1920 x 1080, 1440 x 900, 1280 x 1024. 1280 x 800, 1280 x 720, 1024 x 768
Recording resolution: Up to 8 MP per channel (16 channels at 8 MP)
Compression Format: H.264/H. 264+
POE standard IEEE 802.3at/AF
Hard drive Capacity: Up to 16 TB x2
Network interface: 1x 10/100 Mbit/s RJ45- Port
USB-interface: 2x USB2.0-interface mouse and external memory
Power supply: Direct current 52 V / 4 A.
Operating temperature: 0 C ~ 55 C
This NVR can manage up to 16 IP cameras simultaneously, making WAS it a reliable solution for comprehensive monitoring of large areas. The support of up to 16 TB hard disk (hard disk not included in delivery) enables to backup large video data continuously and without problems with the storage space
The Foscam FNA216HE offers several recording modes, including continuous 24/7-recording, motion-controlled recording and time-controlled recording. In this way, you can adapt your surveillance strategy optimally to your specific requirements.
With support for a resolution of up to 8 megapixels (4K), the FNA216HE provides clear, detailed videos that can detect even the finest details. The integration of the HD 264+ video compression format enables efficient storage of high-quality images, saving storage space and protecting the network bandwidth. This is particularly relevant for multi-camera sites, as it improves the efficiency of transferring and storing large amounts of data.
Thanks to the PoE-support (Power over Ethernet) the installation of the FNA216HE is easy and it is only a single cable is needed for the power supply and the data transfer. This is especially useful if you want to install cameras in places where there are no sockets available or where cable management is a challenge.
The network video recorder has 2 USB 2.0 connections for the mouse and the external memory for exporting recordings.
The motion detection feature alerts you when suspicious activity is being detected.
The network video recorder is easy to use and has a user-friendly interface that enables you easy access and management of video recordings. In addition, you can connect the network video recorder to a monitor or an HD TV via an HDMI cable to view the video recordings on a larger screen.
The FNA216HE is perfectly compatible with the Foscam PC APP (VMS), which provides a user-friendly platform for managing and monitoring the security system. The software provides access to live streams, scanning recordings, and control of all connected cameras from a central location. The NVR also provides the ability to easily expand and customize the system when needed.
Features
Recording mode: Time-controlled / motion detection
Synchronous playback: 16 channels synchronous video playback
Playback mode: Pause / stop / slow / fast / single frame playback
NETWORK PROTOCOL: IP, TCP, UDP, SMTP, DHCP, RTSP
1 x on/off button, 1 x reset button
Operating system: Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android (Foscam APP), iOS (Foscam APP)
Smartphone: IOS, Android, 3G/4G/5G smartphones
Language: 20 languages.
Whats in the Box
Foscam FNA216HE network recorder
USB mouse
SATA-connector cable
Power cable for hard drive
Network cable
Power sup
